PRODUCT

COVERED AL LINE WIRE WEATHERPROOF

    Covered Line Wire AAC Aluminum Conductor

    Covered Line Wire ACSR Aluminum Conductor

    Covered Line Wire Alloy 6201-T81 Aluminum Conductor



COVERED LINE WIRE AAC ALUMINUM CONDUCTOR

Applications

Covered Line Wire is used primarily for overhead secondary distribution lines. It is not an electrically insulated conductor and is treated as bare conductor when installed.


Construction

Conductors are aluminum alloy 1350-H19, 6201-181, or ACSR conductors, concentrically stranded and covered for weather proofing with polyethylene, high density polyethylene (HD) or crosslinked polyethylene (XLP).


Standards

ASTM B-230 - Aluminum 1350-H19 Wire for Electrical Purposes.

ASTM B-231 - Concentric-Lay-Stranded Aluminum Conductors, Coated-Steel Reinforced (ACSR).

ASTM B-1248 - Polyethylene Plastics Molding and Extrusion Materials.

ASTM C-8.35 - Specifications for Weather-Resistant Polyethylene-Covered Wire and Cable.

ICEAS-61-402

NEMA PUB NO. WC 5-1973 - Standards Publication Thermoplastic insulated Wire and Cable for the Transmission and Distribution of Electrical Energy.


COVERED LINE WIRE ACSR ALUMINUM CONDUCTOR

Applications

Covered Line Wire is used primarily for overhead secondary distribution lines. It is not an electrically insulated conductor and is treated as bare conductor when installed.


Construction

Conductors are aluminum alloy 1350-H19, 6201-181, or ACSR conductors, concentrically stranded and covered for weather proofing with polyethylene, high density polyethylene (HD) or crosslinked polyethylene (XLP).


Standards

ASTM B-230 - Aluminum 1350-H19 Wire for Electrical Purposes.

ASTM B-231 - Concentric-Lay-Stranded Aluminum Conductors, Coated-Steel Reinforced (ACSR).

ASTM B-1248 - Polyethylene Plastics Molding and Extrusion Materials.

ASTM C-8.35 - Specifications for Weather-Resistant Polyethylene-Covered Wire and Cable.

ICEAS-61-402

NEMA PUB NO. WC 5-1973 - Standards Publication Thermoplastic insulated Wire and Cable for the Transmission and Distribution of Electrical Energy.


COVERED LINE WIRE ALLOY 6201-T81 ALUMINUM CONDUCTOR

Applications

Covered Line Wire is used primarily for overhead secondary distribution lines. It is not an electrically insulated conductor and is treated as bare conductor when installed.


Construction

Conductors are aluminum alloy 1350-H19, 6201-181, or ACSR conductors, concentrically stranded and covered for weather proofing with polyethylene, high density polyethylene (HD) or crosslinked polyethylene (XLP).


Standards

ASTM B-230 - Aluminum 1350-H19 Wire for Electrical Purposes.

ASTM B-231 - Concentric-Lay-Stranded Aluminum Conductors, Coated-Steel Reinforced (ACSR).

ASTM B-1248 - Polyethylene Plastics Molding and Extrusion Materials.

ASTM C-8.35 - Specifications for Weather-Resistant Polyethylene-Covered Wire and Cable.

ICEAS-61-402

NEMA PUB NO. WC 5-1973 - Standards Publication Thermoplastic insulated Wire and Cable for the Transmission and Distribution of Electrical Energy.
