Galvanized Steel Wire-GSW

Galvanized Clad steel wire earth wire/stay wire/guy wire/spacer cable (GSW)

Overhead ground wire or static wire on transmission lines

Pole or structure guy wires

Messenger cable for field-erected aerial cable

Supplier and manufacturer in China

Send E-mail Get Price Now

Applications

The galvanized steel wire strand is used for overhead ground lines or electrical power transmission lines. Stay wire or guy wire strands are produced for use with poles, towers, or any other form of guying.

Grades

Utilities, Common, Siemens-Martin, High Strength and Extra High Strength. S1A or S1B; S2A or S2B; S3A or S3A.

Finish Coatings

Class A, B and C D E and Bezinal, a superior corrosive coating of 5% Aluminum and 95% Zinc.

Specifications

Including but not limited to:

ASTM A-363 Zinc-Coated (Galvanized) Steel Overhead Ground Wire Strand

ASTM A-475 Zinc-Coated Steel Wire Strand

ASTM A-925 -5 % Aluminum-Mischmetal Alloy-Coated Steel Overhead Ground Wire Strand

ASTM A-855 Zinc-5 % Aluminum-Mischmetal Alloy-Coated Steel Wire Strand

ASTM A-640 Zinc-Coated Steel Strand for Messenger Support of Figure 8 Cable

ASTM B-498 Zinc-Coated (Galvanized) Steel Core Wire for Aluminum Conductors

ASTM B957 Extra-Ultra-Hight strength Zinc-Coated (Galvanized) Steel Core Wire for Aluminum Conductors

BS EN50189 Zinc coated steel wires-Conductor for overhead line

IEC 61089 Zinc coated steel wires-Conductor for overhead line

BS 183-1972 SPECIFICATION FOR GENERAL PURPOSE GALVANIZED STEEL WIRE STRAND

BS 183

Number of wires/Dia.	Approx.Strand Dia.	Minimum Breaking Load of Strand							Approx. Weight
	Approx.Strand Dia.	Grade 350	Grade 480	Grade 700	Grade 850	Grade 1000	Grade 1150	Grade 1300	Approx. Weight
	mm	kN	kN	kN	kN	kN	kN	kN	kg/km
3/1.80	3.9	2.65	3.66	-	-	-	-	-	60
3/2.65	5.7	5.8	7.95	-	-	-	-	-	130
3/3.25	7	8.7	11.95	-	-	-	-	-	195
3/4.00	8.6	13.2	18.1	-	-	-	-	-	295
4/1.80	4.4	3.55	4.9	-	-	-	-	-	80
4/2.65	6.4	7.7	10.6	-	-	-	-	-	172
4/3.25	7.9	11.6	15.9	-	-	-	-	-	260
4/4.00	9.7	17.6	24.1	35.2	-	-	-	-	390
5/1.50	4.1	3.1	4.24	6.18	-	-	-	-	69
5/1.80	4.9	4.45	6.1	8.9	-	-	-	-	95
5/2.65	7.2	9.65	13.25	19.3	-	-	-	-	220
5/3.25	8.8	14.5	19.9	29	-	-	-	-	320
5/4.00	10.8	22	30.15	43.95	-	-	-	-	490
7/0.56	1.7	0.6	0.83	1.2	-	1.7	1.98	2.24	14
7/0.71	2.1	0.97	1.33	1.94	-	2.75	3.19	3.6	28
7/0.85	2.6	1.39	1.9	2.8	-	3.95	4.57	5.15	31
7/0.90	2.7	1.55	2.14	3..1	-	4.45	5.12	5.8	35
7/1.00	3	1.92	2.64	3.85	-	5.5	6.32	7.15	43
7/1.25	3.8	3.01	4.1	6	-	8.55	9.88	11.15	67
7/1.40	4.2	3.75	5.17	7.54	9.16	10.75	12.35	14	84
7/1.60	4.8	4.9	6.75	9.85	11.95	14.1	16.2	18.3	110
7/1.80	5.4	6.23	8.55	12.45	-	17.8	20.5	23.2	140
7/2.00	6	7.7	10.55	15.4	-	22	25.3	28.6	170
7/2.36	7.1	10.7	14.7	21.4	-	30.6	35.2	39.8	240
7/2.65	8	13.5	18.5	27	-	38.6	44.4	50.2	300
7/3.00	9	17.3	23.75	34.65	-	49.5	56.9	64.3	392
7/3.15	9.5	19.1	26.2	38.2	-	54.55	62.75	70.9	430
7/3.25	9.8	20.3	27.85	40.65	-	58.05	66.8	75.5	460
7/3.65	11	25.6	35.15	51.25	-	73.25	84.2	95.2	570
7/4.00	12	30.9	42.2	61.6	-	88	101	114	690
7/4.25	12.8	34.75	47.65	69.5	-	99.3	114	129	780
7/4.75	14	43.4	59.45	86.8	-	124	142.7	161.3	970
19/1.00	5	5.22	7.16	10.45	-	14.92	17.16	19.4	120
19/1.25	6.3	8.16	11.19	16.32	-	23.32	26.81	30.31	180
19/1.40	7	10.24	14.04	20.47	-	29.25	33.64	38.02	230
19/1.60	8	13.37	18.35	26.75	-	38.2	43.93	49.66	300
19/2.00	10	20.9	28.65	41.78	50.74	59.69	68.64	77.6	470
19/2.50	12.5	32.65	44.8	65.29	79.28	93.27	107.3	121.3	730
19/3.00	15	47	64.5	94	114.1	134.3	154.5	174.6	1050
19/3.55	17.8	65.8	90.27	131.6	159.9	188	216.3	244.5	1470
19/4.00	20	83.55	114.6	167.1	203	238.7	274.6	310.4	1870
19/4.75	23.8	117.85	161.4	235.7	286	336.7	387.2	437.7	2630

ASTM A475

Number of Wires/Dia.	Approx.Strand Dia.		Siemem Martin Grade	High Strength Grade	Extra-high Strength Grade	Approx.Weight
	Inch	mm	KN	KN	KN	kg/km
3/2.64	7/32	5.56	10.409	15.569	21.796	131
3/3.05	1/4	6.35	13.523	21.04	29.981	174
3/3.05	1/4	6.35	-	-	-	174
3/3.30	9/32	7.14	15.035	23.398	33.362	204
3/3.68	5/16	7.94	18.193	28.246	40.479	256
3/4.19	3/8	9.52	24.732	37.187	52.489	328
7/1.04	1/8	3.18	4.048	5.916	8.18	49
7/1.32	5/32	3.97	6.539	9.519	13.078	76
7/1.57	3/16	4.76	8.452	12.677	17.748	108
7/1.65	3/16	4.76	-	-	-	118
7/1.83	3/16	5.56	11.387	17.126	24.02	145
7/2.03	7/32	6.35	14.012	21.129	29.581	181
7/2.36	1/4	7.14	18.905	28.469	39.812	243
7/2.64	9/32	7.94	23.798	35.586	49.82	305
7/2.77	5/16	7.94	-	-	-	335
7/3.05	3/8	9.52	30.915	48.04	68.503	407
7/3.68	7/16	11.11	41.591	64.499	92.523	594
7/4.19	1/2	12.7	53.823	83.627	119.657	768
7/4.78	9/16	14.29	69.837	108.981	155.688	991
7/5.26	5/8	15.88	84.961	131.667	188.605	1211
19/2.54	1/2	12.7	56.492	84.961	118.768	751
19/2.87	9/16	12.49	71.616	107.202	149.905	948
19/3.18	5/8	15.88	80.513	124.995	178.819	1184
19/3.81	3/4	19.05	116.543	181.487	259.331	1719
19/4.50	7/8	22.22	159.691	248.211	354.523	2352
19/5.08	1/1	25.4	209.066	325.61	464.839	2384
37/3.63	1/1	25.4	205.508	319.827	456.832	3061
37/4.09	11/8	28.58	262	407.457	581.827	4006
37/4.55	11/4	31.75	324.72	505.318	721.502	4833

ASTM B957

Grade 4 Extra-High-Strength Tensile Requirements (Metric)

Specified Diameter, mm	Stress at 1% Extension,	Ultimate Tensile Strength,	Elongation in 250 mm, min %
	min, MPa	min, MPa
1.27 to 2.28, incl	1550	1825	3.0
2.29 to 3.04, incl	1515	1790	3.0
3.05 to 3.55, incl	1480	1760	3.5
3.56 to 4.82, incl	1450	1725	3.5

Grade 5 Ultra-High-Strength Tensile Requirements (Metric)

Specified Diameter, mm	Stress at 1% Extension,	Ultimate Tensile Strength,	Elongation in 250 mm, min %
	min, MPa	min, MPa
1.27 to 2.28, incl	1580	1965	3.0
2.29 to 3.04, incl	1550	1900	3.0
3.05 to 3.55, incl	1515	1860	3.5
3.56 to 4.82, incl	1480	1825	3.5
