Venezuela Triplex Wire Overhead Aluminum Cable from Manufacturer in China
Application of Tripelx Wire
Triplex overhead aluminum cable branch cables are commonly used for overhead power lines and service lines of 0.6/1kV, 6/10kV and below, and are usually used to transmit power from utility poles to residential or commercial buildings.
1. Residential power delivery: Triplex overhead aluminum cable is commonly used for delivering power from a utility pole to a residential building. The cable is designed to withstand the outdoor environment and provide a reliable and safe power supply to the building.
2. Commercial power delivery: Triplex overhead aluminum cable is also used for delivering power to commercial buildings such as shops, offices, and factories. The cable is available in different sizes and configurations to suit the specific power requirements of the building.
3. Street lighting: Triplex overhead aluminum cable is used for powering street lights in urban and suburban areas. The cable is designed to withstand harsh weather conditions and provide a long-lasting and reliable power supply to the lights.
4. Temporary power supply: Triplex overhead aluminum cable can be used for temporary power supply to construction sites, outdoor events, and other temporary installations. The cable can be easily installed and removed, making it a convenient option for temporary power needs.
ASTM B-230,B-231,B-232 and B-339
ICEA S-76-474
Triplex Wire Specification
Code Name | Phase Conductor | Bare Neutral Messenger | Weight Per 1000ft (lbs) | Ampacity(amps) | ||||||
Size AWG | Stranding | Insulation Thickness(mls) | Size AWG | Stranding | Breaking Strength(lbs) | XLPE | Poly | XLPE | Poly | |
6201 ALLOY NEUTRAL-MESSENGER | ||||||||||
Minex | 6 | Solid | 45 | 6 | 7 | 1,110 | 106.6 | 102.9 | 85 | 70 |
Hippa | 6 | 7 | 45 | 6 | 7 | 1,110 | 113.2 | 105.7 | 85 | 70 |
Prawn | 4 | Solid | 45 | 4 | 7 | 1,760 | 158.4 | 154.1 | 115 | 90 |
Barnacles | 4 | 7 | 45 | 4 | 7 | 1,760 | 168.3 | 158.2 | 115 | 90 |
Shrimp | 2 | 7 | 45 | 2 | 7 | 2,800 | 253.7 | 239.7 | 150 | 120 |
Gammarus | 1/0 | 7 | 60 | 1/0 | 7 | 4,460 | 411.7 | 386.0 | 205 | 160 |
Leda | 1/0 | 19 | 60 | 1/0 | 7 | 4,460 | 402.7 | 386.0 | 205 | 160 |
Dungenese | 2/0 | 7 | 60 | 2/0 | 7 | 5,390 | 506.8 | 476.3 | 235 | 185 |
Cyclops | 2/0 | 19 | 60 | 2/0 | 7 | 5,390 | 495.3 | 476.3 | 235 | 185 |
Dlustra | 3/0 | 19 | 60 | 3/0 | 7 | 6,790 | 611.4 | 589.1 | 275 | 215 |
Lepas | 4/0 | 19 | 60 | 4/0 | 7 | 8,560 | 757.1 | 730.5 | 315 | 245 |
6201 ALLOY REDUCED NEUTRAL-MESSENGER | ||||||||||
Artemia | 4 | Solid | 45 | 6 | 7 | 1,110 | 141.4 | 137.1 | 115 | 90 |
Crab | 4 | 7 | 45 | 6 | 7 | 1,110 | 151.3 | 141.2 | 115 | 90 |
Solaster | 2 | 7 | 45 | 4 | 7 | 1,760 | 226.6 | 212.6 | 150 | 120 |
Sandcrab | 1/0 | 7 | 60 | 2 | 7 | 2,800 | 368.8 | 343.1 | 205 | 160 |
Echinus | 1/0 | 19 | 60 | 2 | 7 | 2,800 | 358.8 | 343.1 | 205 | 160 |
Crayfish | 2/0 | 7 | 60 | 1 | 7 | 3,530 | 452.6 | 422.5 | 235 | 185 |
Sipho | 2/0 | 19 | 60 | 1 | 7 | 3,530 | 441.0 | 422.5 | 235 | 185 |
Fulgar | 3/0 | 19 | 60 | 1/0 | 7 | 4,460 | 543.4 | 521.1 | 275 | 215 |
Arca | 4/0 | 19 | 60 | 2/0 | 7 | 5,390 | 671.2 | 644.6 | 315 | 245 |
Code Name | Phase Conductor | Bare Neutral Messenger | Weight Per 1000ft (lbs) | Ampacity(amps) | ||||||
Size AWG | Stranding | Insulation Thickness(mls) | Size AWG | Stranding | Breaking Strength(lbs) | XLPE | Poly | XLPE | Poly | |
WITH ACSR REDUCED SIZE MESSENGER | ||||||||||
Scallop | 4 | Solid | 45 | 6 | 6/1 | 1,190 | 148 | 144 | 115 | 90 |
Strombus | 4 | 7/w | 45 | 6 | 6/1 | 1,190 | 158 | 148 | 115 | 90 |
Cockle | 2 | 7/w | 45 | 4 | 6/1 | 1,860 | 233 | 227 | 150 | 120 |
Janthina | 1/0 | 7/w | 60 | 2 | 6/1 | 2,850 | 376 | 365 | 205 | 160 |
Ranella | 1/0 | 19/w | 60 | 2 | 6/1 | 2,850 | 372 | 362 | 205 | 160 |
Cavolinia | 2/0 | 7/w | 60 | 1 | 6/1 | 3,550 | 462 | 451 | 235 | 185 |
Clio | 2/0 | 19/w | 60 | 1 | 6/1 | 3,550 | 458 | 446 | 235 | 185 |
Sanddollar | 3/0 | 7/w | 60 | 1/0 | 6/1 | 4,380 | 570 | 557 | 275 | 215 |
Aega | 3/0 | 19/w | 60 | 1/0 | 6/1 | 4,380 | 565 | 552 | 275 | 215 |
Cuttlefish | 4/0 | 7/w | 60 | 2/0 | 6/1 | 5,310 | 706 | 691 | 315 | 245 |
Cerapus | 4/0 | 19/w | 60 | 2/0 | 6/1 | 5,310 | 699 | 684 | 315 | 245 |
Cowry | 336.4 | 19/w | 80 | 4/0 | 6/1 | 8,350 | 1135 | 1093 | ||
