Iraq ACSR 120-20mm2 for Overhead Line
DIN 48204 70/12 120/20 ACSR /SCA bare conductor cable overhead transmission lines
| CODE | CALCULATED AREA | STRAND/ DIA. | O.D. | LINEAR MASS | STRENGTH | RESISTANCE AT 20℃ | |||||
| Al/St. | Al. | Steel | Total | Al. | Steel | Al. | St. | Total | |||
| mm2 | mm2 | mm2 | mm2 | mm | mm | mm | kg/km | kg/km | kg/km | daN | Ω/km |
| 120/20 | 121.06 | 19.8 | 141.4 | 26/2.44 | 7/1.90 | 15.5 | 336 | 158 | 494 | 4565 | 0.2374 |
| Code Name | Stranding | Section | Overall Diameter | Conductor Weight | Rated Strength | Electrical Resistance | |
| Aluminum | Steel | mm2 | mm | kg/km | kN | DC.20°C | |
| No. x Φmm | Ω/km | ||||||
| 16/2.5 | 6/1.80 | 1/1.80 | 17.85 | 5.4 | 62 | 5.95 | 1.8792 |
| 25/4 | 6/2.25 | 1/2.25 | 27.80 | 6.8 | 97 | 9.20 | 1.2027 |
| 35/6 | 6/2.70 | 1/2.70 | 40.00 | 8.1 | 140 | 12.65 | 0.8353 |
| 44/32 | 14/2.00 | 7/2.40 | 75.70 | 11.2 | 372 | 45.00 | 0.6566 |
| 50/8 | 6/3.20 | 1/3.20 | 56.30 | 9.6 | 196 | 17.10 | 0.5946 |
| 50/30 | 12/2.33 | 7/2.33 | 81.00 | 11.7 | 378 | 43.80 | 0.5644 |
| 70/12 | 26/1.85 | 7/1.44 | 81.30 | 11.7 | 284 | 26.80 | 0.413 |
| 95/15 | 26/2.15 | 7/1.67 | 109.70 | 13.6 | 383 | 35.75 | 0.3058 |
| 95/55 | 12/3.20 | 7/3.20 | 152.80 | 16.0 | 712 | 79.35 | 0.2992 |
| 105/75 | 14/3.10 | 19/2.25 | 181.50 | 17.5 | 891 | 108.45 | 0.2733 |
| 120/20 | 26/2.44 | 7/1.90 | 141.40 | 15.5 | 494 | 45.65 | 0.2374 |
| 120/70 | 12/3.60 | 7/3.60 | 193.30 | 18.0 | 901 | 100.00 | 0.2364 |
| 125/30 | 30/2.33 | 7/2.33 | 157.70 | 16.1 | 591 | 57.60 | 0.2259 |
| 150/25 | 26/2.70 | 7/2.10 | 173.10 | 17.1 | 605 | 55.25 | 0.1939 |
| 170/40 | 30/2.70 | 7/2.70 | 211.90 | 18.9 | 794 | 76.75 | 0.1682 |
| 185/30 | 26/3.00 | 7/2.33 | 213.60 | 19.0 | 746 | 66.20 | 0.1571 |
| 210/35 | 26/3.20 | 7/2.49 | 243.20 | 20.3 | 850 | 74.90 | 0.138 |
| 210/50 | 30/3.00 | 7/3.00 | 261.60 | 21.0 | 981 | 93.90 | 0.1363 |
| 230/30 | 24/3.50 | 7/2.33 | 260.70 | 21.0 | 877 | 73.10 | 0.1249 |
| 240/40 | 26/3.45 | 7/2.68 | 282.50 | 21.9 | 987 | 86.40 | 0.1188 |
| 265/35 | 24/3.74 | 7/2.49 | 297.80 | 22.4 | 1002 | 83.05 | 0.1117 |
| 300/50 | 26/3.86 | 7/3.00 | 353.70 | 24.5 | 1236 | 107.00 | 0.0949 |
| 305/40 | 54/2.68 | 7/2.68 | 344.10 | 24.1 | 1160 | 99.40 | 0.0949 |
| 340/30 | 48/3.00 | 7/2.33 | 369.10 | 25.0 | 1180 | 92.90 | 0.0853 |
| 380/50 | 54/3.00 | 7/3.00 | 431.50 | 27.0 | 1453 | 123.10 | 0.0757 |
| 385/35 | 48/3.20 | 7/2.49 | 420.10 | 26.7 | 1344 | 104.80 | 0.0749 |
| 435/55 | 54/3.20 | 7/3.20 | 490.60 | 28.8 | 1653 | 136.45 | 0.0666 |
| 450/40 | 48/3.45 | 7/2.68 | 488.20 | 28.7 | 1561 | 120.75 | 0.0644 |
| 490/65 | 54/3.40 | 7/3.40 | 553.90 | 30.6 | 1866 | 153.10 | 0.059 |
| 495/35 | 45/3.74 | 7/2.49 | 528.20 | 29.9 | 1616 | 121.80 | 0.0585 |
| 510/45 | 48/3.68 | 7/2.87 | 555.50 | 30.7 | 1778 | 136.65 | 0.0565 |
| 550/70 | 54/3.60 | 7/3.60 | 621.30 | 32.4 | 2092 | 170.60 | 0.0526 |
| 560/50 | 48/3.86 | 7/3.00 | 611.20 | 32.2 | 1954 | 148.95 | 0.0515 |
| 570/40 | 45/4.02 | 7/2.68 | 610.70 | 32.2 | 1888 | 136.20 | 0.0512 |
| 650/45 | 45/4.30 | 7/2.87 | 698.80 | 34.0 | 2171 | 155.50 | 0.0458 |
| 680/85 | 54/4.00 | 19/2.40 | 764.60 | 36.0 | 2566 | 206.25 | 0.0426 |
| 1045/45 | 72/4.30 | 7/2.87 | 1090.90 | 43.0 | 3251 | 217.60 | 0.0277 |
